GTCO “Super L-VI” Hard Board Digitizers

PHsl3tablets250              photo_superl_372x265

On-Line Purchase



The GTCO Super L-VI is the next generation of the well-known Super L Series of tablet (hard-board) digitizers, delivering outstanding performance at a competitive price.   Built with advanced materials, including a tough Nevamar work surface, your Super L-VI tablet will continue to perform to factory specifications for many years.

Professionals in construction estimating, CAD, textiles and other fields will appreciate the Super L-VI’s added flexibility and improved performance. In addition to all the technology and design features you’ve come to know from the Super L III, the Super L VI offers high resolution, enhanced emulations and gives you the choice of using a corded or cordless pointing device on the same tablet.     GTCO digitizers are compatible with all types of construction software:  Agtek, Paydirt, Quest, Insite, Timberline, OnCenter, R.S. Means, WinEst, and also AutoCAD and various CAD, GIS  and apparel pattern (PAD) design applications.



Features:
  Choice of corded or cordless pointing devices.
  Compatible with virtually all PC software packages.
  Patented sensing technology and precision pointing devices provide high accuracy.
  Quick set-up—Integrated USB connection allows digitizer to be powered through USB port on connected computer.
  Easy to use—SuperSet Menu allows simple software configuration and switching between applications.
  Light weight—lightest weight rigid tablet available provides easier set-up and lower shipping costs.
  Durable and dependable—made with state-of-the-art materials and backed by a 2-year US warranty.



What’s in the Box:
  Super L-VI Tablet and Controller
  Choice of Corded or Cordless Pointing Device
  CD with Software Driver and Users Manual
  USB Cable
  Optional Pointing Devices: 4-Button Cursor (corded or cordless); 16-Button Cursor (corded or cordless); Click-Tip Pen (corded or cordless); 5-Button Mouse (cordless), Inking Inserts for Corded Pen.
  Optional RS-232 Serial kit with power supply and cable
  Optional Mounting Brackets
  Optional Plan Hold-Down (Model 30/36 and 36/48 only)
  Optional Digitizer Stand: Dakota Pedestals/Workstations.



On-Line Purchase



Models:

Model Active Area Footprint Weight Shipping Wt (Avg)
2024 20 in x 24 in
(508 mm x 610 mm)
29 in x 34 in
(737 mm x 864 mm)
13 lb
(5.9 kg)
31 lb
(14.1 kg)
2436 24 in x 36 in
(610 mm x 914 mm)
32.5 in x 46 in
(826 mm x 1168 mm)
19 lb
(8.6 kg)
42 lb
(19.1 kg)
3036 30 in x 36 in
(763 mm x 914 mm)
35.3 in x 44.5 in
(896 mm x 1130 mm)
19 lb
(8.6 kg)
42 lb
(19.1 kg)
3648 36 in x 48 in
(914 mm x 1219 mm)
44.5 in x 60 in
(1130 mm x 1524 mm)
30 lb
(13.6 kg)
70 lb
(31.8 kg)
4460 44 in x 60 in
(1117 mm x 1524 mm)
52.5 in x 69 in
(1333 mm x 1753 mm)
40 lb
(18.2 kg)
80 lb
(36.4 kg)
